MAIN FEATURES

• RoHS Compliance
• Bright LED display for showing parameters for both EB & DG
• Displays full range of parameters
• Basic : Vll, VLn, A (Avg. & Phase wise), F
• Power: W, PF (Avg. & Phase wise)
• Energy : Wh
• Load Hours, Run Hours, Old Wh, Old Load Hours for both EB & DG.
• DG Sensing input - 230 VAC
• Auto scaling capability in adjustment of Kilo, Mega, Giga.
• Positive energy accumulation even with CT polarity reversal with reverse lock program.
• High Accuracy with class 1 as per IEC 62053-21 & class 0.5 as per IEC 62053-22
• Site selectable CT/PT ratios
• Site selectable CT Secondary 1A/5A
• Universal control power supply 80 – 300V AC/DC, 40-70Hz
• Password protection for tamper proofing
• Seamless integration with EMS/SCADA system with RS485 serial channel communication, Industry standard Modbus RTU protocol.
• Provision for Tamper proofing with meter casing*
• *optional strip for tamper proofing
