3 pole power manual motor starter with rotary knob control protection against overload, short circuit, phase Failure.
The MS116 manual motor starter (also known as motor protection circuit breaker or manual motor protector) is a compact 45 mm width device with a rated operational current of Ie = 0.16 to 32 A.
This device is used to manually switch on and off motors and to protect them reliably and without the need for a fuse from short-circuits, overload and phase failures.
The manual motor starter offers a rated service short-circuit breaking capacity Ics = 100 kA at 400 VAC and trip class 10. Further features are the build-in disconnect function, temperature compensation, trip-free mechanism and a rotary handle with a clear switch position indication.
The manual motor starter is suitable for three- and single-phase applications.
The handle is lockable to protect against unauthorized changes.
Number of Poles : 3
Product Net Weight : 0.215 kg
Product Net Width : 45 mm
Product Net Height :90 mm
Product Net Depth / Length : 86.75 mm
Rated Operational Voltage : 690 V AC,250 V DC
Rated Frequency (f) : Main Circuit 50 Hz/Main Circuit 60 Hz
Pollution Degree : 3
Degree of Protection : Housing IP20,Main Circuit Terminals IP10
Mounting Position : Position 1 to 6
Contact Position Indication : ON / OFF / TRIP
Actuator Type : Rotary Handle
Electrical Durability : 50000 cycle
Mechanical Durability : 100000 cycle
Terminal Type : Screw Terminals
ABB Manual motor starter MS116-0.16 1SAM250000R1001 with short circuit, overload protection
